Description
Redefining metal AM safety with ISO 21904 compliance and ignition risk.
[PURE-AIR] equipment has 18KPa negative pressure + automatic pulse cleaning system, 0.3 micron purification efficiency of 99.99%, suitable for Class 100 dust-free workshop, direct discharge reaches international standards!
Key features
- Explosion-Safe Purification
- Anti-Static PTFE Matrix:
specialized filters (flame-retardant/ESD-safe) capture 99.99% of sub-0.1μm particles
Aerodynamic pre-separation triples dust load capacity - Catalytic Oxidation: Neutralizes NOₓ/ozone from plasma sintering
- Cleanroom-Optimized Design
- Ultra-compact chassis (40% space savings)
- Cleanroom-grade casters: 20-second zone transfers
- 7″ Touchscreen: Real-time PM1.0/VOC/temperature monitoring
- Dynamic negative pressure (8-18KPa) for reactive material processing
- Industry 4.0 Integration
- RS-485/MQTT protocols for central AM control
- GMP/ISO Class 5 compatibility
- Patented pulse cleaning (400% efficiency gain)
- Hermetic filter swaps prevent powder exposure
- 30,000-hour aviation-grade motor (≤65dB)
Table parameters：
| Model | PA-D500i | PA-D800i | PA-D1600i | PA-D2400i | |
| Airflow | 500m³/hr | 800m³/hr | 1600m³/hr | 2400m³/hr | |
| Pressure | 10000Pa | 10000Pa | 10000Pa | 10000Pa | |
| Rated power | 1.1kw | 1.3kw | 2.3kw | 3.5kw | |
| Input voltage / Frequency | 90v-110v / 210-257v, 1ph, 50/60Hz | ||||
| Control system | PURE-AIR INTELLIGENT PURIFICATION SYSTEM (PIPS) | ||||
| Air quality sensor (Optional) | PM1.0 / VOC / HCL / O3 / Odor | ||||
| Filter | Pre filter | F9 accordion filter bag (95%@0.9um) | Flame retardant PTFE cartridge filter | ||
| Main filter | H14 deeppleat filter (99.997% @0.3um) | ||||
| Noise level * | < 65dBA | < 63dBA | < 65dBA | < 68dBA | |
| Dimensions (W*D*H) | 520*360*555mm | 500*597*1296mm | 670*794*1570mm | 750*907*1564mm | |
| Weight | 25kg | 86kg | 180kg | 200kg | |
| Inlet size | 75mm / 100mm | 100mm / 125mm | 150mm | 200mm | |
| Cabinet construction | Powder coated mild steel / Brushed stainless steel | ||||
| * At typical operating speed testing data. | |||||
