Description
Where advanced fume control meets zero downtime and 50% lower maintenance costs.
Specialized to treat carbon steel/stainless steel/copper welding smoke!
[PURE-AIR] Fume extraction system uses 18KPa hurricane negative pressure + high-precision purification system, 0.3 micron metal dust interception rate of 99.99%, solves fume hazards, and directly discharges to international standards!
Key features
- Welding-Specific Filtration Matrix
► Custom Cartridges:
Anti-static/flame-retardant/moisture-resistant options
Optimized for stainless/galvanized/carbon steel fumes
►SparkShield™ Pre-Chamber:
Captures 85% of sparks and slag
Extends filter life by 60%
- Space-Optimized Performance
► Ultra-compact design (40% space savings)
► Robotic cell-compatible with quick-connect ports
► Heavy-duty casters: 15-second line transfers
- Smart Welding Cell Integration
► 7″ Touchscreen: Real-time PM1.0/O₃/humidity monitoring
► AI Dynamic Suction™: Auto-adjusts 10-18KPa negative pressure
► RS-485/MQTT protocols for centralized weld monitoring
► Pulse auto-cleaning (320% efficiency gain)
- Uncompromised Durability
► Hermetic seal filter swaps (<60 seconds)
► Aviation-grade alloy impeller (<65dB)
► 30,000-hour maintenance-free operation
► OSHA compliant
Table Parameters：
| Application conditions | Processing materials | Laser cutting: Carbon steel, stainless steel, galvanized sheet and other materials. | ||
| Working format | 900*130cm | 100*160cm | 100*200cm | |
| Model | PA-D800i | PA-D1600i | PA-D2400i | |
| Airflow | 800m³/hr | 1600m³/hr | 2400m³/hr | |
| Pressure | 10000Pa | 10000Pa | 10000Pa | |
| Rated power | 1.3kw | 2.3kw | 3.5kw | |
| Input voltage / Frequency | 90v-110v / 210-257v, 1ph, 50/60Hz | |||
| Control system | PURE-AIR INTELLIGENT PURIFICATION SYSTEM (PIPS) | |||
| Air quality sensor (Optional) | PM1.0 / VOC / HCL / O3 / Odor | |||
| Filter | Pre filter | Flame retardant PTFE cartridge filter | ||
| Main filter | H14 deeppleat filter (99.997% @0.3um) | |||
| Noise level * | < 63dBA | < 65dBA | < 68dBA | |
| Dimensions (W*D*H) | 500*597*1296mm | 670*794*1570mm | 750*907*1564mm | |
| Weight | 86kg | 180kg | 200kg | |
| Inlet size | 100mm / 125mm | 150mm | 200mm | |
| Cabinet construction | Powder coated mild steel / Brushed stainless steel | |||
| * At typical operating speed testing data. | ||||
